50w led flood security light
We supply slim shape led flood light with full range from 50w to 400w that used for building outline, stadium, overpass, monument, park and flower bed, high mast, tower crane, stadium, street, highway, square,billboard, exhibition hall, top quality with CE RoHS Certificates, 5 years Warranty. LED Orientalight Co., Limited has 14 years production experience for led flood light, our products reaching the worldwide markets. If you are looking for a reliable supplier for high quality 50w led flood light, please feel free to contact us.
Model:FL550
Send Inquiry
Product Description
1. Product Introduction of the 50w led flood security light
LED flood light is mainly used for architectural decorative lighting and commercial space lighting. The decorative components are heavier, and many of its appearances are square. Because heat dissipation generally has to be considered, its appearance is different from traditional lighting. There are still some differences in the floodlights. LED floodlights are actually composed of LED light cups, but they have some of their own characteristics. 1) High-purity aluminum reflector, the most accurate beam and the best reflection effect; 2) Symmetrical narrow-angle, wide-angle and asymmetric light distribution systems; 3) The lamps are equipped with scale plates to facilitate the adjustment of the irradiation angle.
2.Product Parameter (Specification) of the 50w led flood security light.
|
Item No. |
FL550 |
FL580 |
FL5100 |
FL5150 |
FL5200 |
FL5300 |
|
Product Model |
LM-FLG310O050Y05-WW/NW/CW |
LM-FLG354O080Y05-WW/NW/CW |
LM-FLG402O100Y05-WW/NW/CW |
LM-FLG430O150Y05-WW/NW/CW |
LM-FLG470O200Y05-WW/NW/CW |
LM-FLG565O300Y05-WW/NW/CW |
|
Size(mm) |
310.47*220*50mm |
354.32*245*55mm |
402.32*295*60mm |
430.25*330*60mm |
470.25*360*60mm |
565*457*65mm |
|
Input Voltage(V) |
AC100-277V 50/60Hz |
AC100-277V 50/60Hz |
AC100-277V 50/60Hz |
AC100-277V 50/60Hz |
AC100-277V 50/60Hz |
AC100-277V 50/60Hz |
|
Color(CCT) |
3000K/4000K/5000K/6500K |
3000K/4000K/5000K/6500K |
3000K/4000K/5000K/6500K |
3000K/4000K/5000K/6500K |
3000K/4000K/5000K/6500K |
3000K/4000K/5000K/6500K |
|
Luminous |
6500lm |
10400lm |
13000lm |
19500lm |
26000lm |
39000lm |
|
LED Quantity |
64pcs |
96pcs |
128pcs |
192pcs |
240pcs |
384pcs |
|
Led Type |
Osram or Lumileds |
Osram or Lumileds |
Osram or Lumileds |
Osram or Lumileds |
Osram or Lumileds |
Osram or Lumileds |
|
CRI |
>80Ra |
>80Ra |
>80Ra |
>80Ra |
>80Ra |
>80Ra |
|
PF |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
|
Beam Angle |
30°/60°/90°/150*80° |
30°/60°/90°/150*80° |
30°/60°/90°/150*80° |
30°/60°/90°/150*80° |
30°/60°/90°/150*80° |
30°/60°/90°/150*80° |
|
Lamp body material |
Aluminium Alloy |
Aluminium Alloy |
Aluminium Alloy |
Aluminium Alloy |
Aluminium Alloy |
Aluminium Alloy |
|
Installation |
Bracket |
Bracket |
Bracket |
Bracket |
Bracket |
Bracket |
|
Black |
Black |
Black |
Black |
Black |
Black |
|
|
Product certificates |
CE RoHS |
CE RoHS |
CE RoHS |
CE RoHS |
CE RoHS |
CE RoHS |
|
Lifespan |
50,000hours |
50,000hours |
50,000hours |
50,000hours |
50,000hours |
50,000hours |
|
Warranty |
5 years |
5 years |
5 years |
5 years |
5 years |
5 years |
Lead time:
|
Quantity(Pieces) |
Sample |
1-500 |
500-2000 |
2001-10000 |
>10000 |
|
Time(Days) |
Inventory |
7 |
7-10 |
15 |
15-20 |
3.Product Feature And Application of the 50w led flood lighting:
LED Flood Lights are widely used in billboard, buildings,corridor, landscape, show window, garage, supermarket,squares, stadium, tunnel, high mast, tower crane, stadium, street, highway, square,billboard, exhibition hall,parking lot, tennis court,gymnasium,park,garden,building facade,any indoor or outdoor areas.
4. Product Details of the 50w LED flood lights:
• 3030 SMD LED, completed light efficiency 130lm/w
• Mean well driver/sosen led driver etc
• IP65 waterproof
• Better heat dissipation with big aluminum PCB and SMD
• Consistent color rendering (CRI) > 80
• Warranty: 5 years
Explosion View
5. Product Package and Installation of the led flood lights
6. Deliver,Shipping And Serving of the 50w LED flood lights
Our led flood light has strong packaging design, the product will not be worn or broken during transportation, which can ensure the product reach your hand safely.
1) Our quality control (4 times 100% checking and 24 hours aging)
1.Raw material 100% check before production.
2.order must have a first sample and full check before manufacturing process.
3.100% check before aging.
4.24 hours aging with 500 times on off testing.
5.100% final inspection before packing.
2) Our service:
1.Your inquiry related to our products or prices will be replied in 2 hours even during holiday.
2.Well-trained and experienced staffs to answer all your inquiries in fluent English.
3.We accept “support” OEM&ODM orders
4.Distributorship is offered for your unique design and some our current models.
5.Protection of your sales are ideas of design and all your private information.
3) Warranty terms:
1/1 replacement of defects within the warranty period.
7.FAQ
Q: Where is your factory?
A: BaoAn,ShenZhenCity Guangdong Province.
Q: What kind of certificate you have?
A: All kinds of certificates can be supply based on large purchase quantity.
Q:How long will it take if asking for the samples?
A: General speaking, 3-5 working days if asking for our regular items.
Q:What is your lead time for the mass products such as 5000 units per item?
A: General speaking, about 35 days after getting down payment and confirmation about the samples.
Q:What is your payment terms?
A: T/T, by cash, western union, or L/C.
Q: What are your market reach throughout the region?
A:Our markets around the world in every corner, we have 14 years of experience in foreign trade.
Q:What is your main product line is made?
A:We mainly produce led application classes and industrial lighting fixtures. Including daily life indoor lighting.
(led track light, led panel light, led strip, led linear light, led high bay, led floodlight, led street light etc)
Q:Your factory or trading company?
A:We are a factory, we provide OEM services.
