1200w led high mast stadium light
The 1200w LED high mast stadium light provides an extremely high luminous flux of up to 192,000 lumens or higher, enabling it to cover a very large area with a uniform light distribution. It is a durable and long-lasting lighting solution that replaces traditional high-intensity discharge (HID) lights, providing exceptional energy efficiency, cost savings, and maintenance benefits.
Model:LS41200
Send Inquiry
Product Description
1. Product Introduction of the 1200w LED high mast stadium light
1200w LED high mast stadium light is a high-performance lighting fixture designed for illuminating large areas, such as sports stadiums, airfields, industrial sites, and other outdoor spaces that require high-intensity lighting.
Made with high-quality and durable materials such as aluminum, steel, tempered glass, and polycarbonate, a typical 1200w LED high mast stadium light is designed to withstand harsh weather and environmental conditions. They are often IP-rated to ensure protection against water, dust, and other debris.
These LED high mast lights are equipped with advanced smart control options that allow operators to adjust brightness based on specific lighting application needs. This feature optimizes energy consumption, minimizes light pollution, and reduces operating costs.
The 1200w LED high mast stadium light is a powerful, energy-efficient, and cost-effective lighting solution that is widely used in industrial, commercial, and outdoor lighting applications. It offers excellent light quality and uniformity, excellent durability, and low maintenance requirements.
2.Product Parameter (Specification) of the 1200w led high mast stadium light.
Item No.
LS4480
LS4720
LS4960
LS41200
LS41500
Product Model
LM-LSG5050P480S04-CW
LM-LSG5050P720S04-CW
LM-LSG5050P960S04-CW
LM-LSG5050P1200S04-CW
LM-LSG5050P1500S04-CW
Size(mm)
580.6*353*180mm
590.6*548.8*195mm
692.8*590.6*195mm
836.8*590.6*195mm
980.8*590.6*195mm
Input Voltage(V)
AC100-277V 50/60Hz
AC100-277V 50/60Hz
AC100-277V 50/60Hz
AC100-277V 50/60Hz
AC100-277V 50/60Hz
Color(CCT)
3000K/4000K/5000K/6000K
3000K/4000K/5000K/6000K
3000K/4000K/5000K/6000K
3000K/4000K/5000K/6000K
3000K/4000K/5000K/6000K
Luminous
76,800lm
115,200lm
153,600lm
192.000lm
240.000lm
Led Type
Osram or Lumileds
Osram or Lumileds
Osram or Lumileds
Osram or Lumileds
Osram or Lumileds
CRI
>80Ra
>80Ra
>80Ra
>80Ra
>80Ra
PF
>0.95
>0.95
>0.95
>0.95
>0.95
Beam Angle
20°/40°/60°/90° Available
20°/40°/60°/90° Available
20°/40°/60°/90° Available
20°/40°/60°/90° Available
20°/40°/60°/90° Available
Lamp body material
Aluminium Alloy
Aluminium Alloy
Aluminium Alloy
Aluminium Alloy
Aluminium Alloy
Installation
Bracket
Bracket
Bracket
Bracket
Bracket
Body Color
Black
Black
Black
Black
Black
Product certificates
CE RoHS
CE RoHS
CE RoHS
CE RoHS
CE RoHS
Lifespan
50,000hours
50,000hours
50,000hours
50,000hours
50,000hours
Warranty
5 years
5 years
5 years
5 years
5 years
3. Product Feature And Application of the 1200w led high mast stadium light
LED high mast stadium lights are versatile lighting fixtures that can be used in various outdoor applications where large areas need to be well-illuminated. Their energy efficiency, long lifespan, and superior light distribution make them an ideal choice for illuminating stadiums, arenas, parking lots, airports, industrial facilities, and public spaces.
4. Product Details of the 1200w led stadium lights:
Item No.： LS41200
Product Model: LM-LSG5050P1200S04-CW
Product Power： 1200W
Product Size： 836.8*590.6*195mm
Input Voltage： 100-277V 50/60 Hz
Led Qty： 480pcs
Product CCT： 1800-6500K Optional
Product Ra： ≥80Ra
Product PF： ≥0.95
Luminous Flux： 192,000lm
Beam Angle： 20°/40°/60°/90° Available
IP Rating： IP66
Net Weight： 18Kg
Gross Weight： 19.85Kg
Qty / CTN： 1 pc/ CTN
Carton Size： 887*641*243mm
5. Product Qualification of the 1200w led stadium lights.
6. Deliver,Shipping And Serving of the 1200w led high mast stadium light.
Our led stadium light has strong packaging design, the product will not be worn or broken during transportation, which can ensure the product reach your hand safely.
1) Our quality control (4 times 100% checking and 24 hours aging)
1.Raw material 100% check before production.
2.order must have a first sample and full check before manufacturing process.
3.100% check before aging.
4.24 hours aging with 500 times on off testing.
5.100% final inspection before packing.
2) Our service:
1.Your inquiry related to our products or prices will be replied in 2 hours even during holiday.
2.Well-trained and experienced staffs to answer all your inquiries in fluent English.
3.We accept “support” OEM&ODM orders
4.Distributorship is offered for your unique design and some our current models.
5.Protection of your sales are ideas of design and all your private information.
3) Warranty terms:
1/1 replacement of defects within the warranty period.
7.FAQ
Q: Where is your factory?
A: ShenZhen City, Guangdong Province.
Q: What is your terms of delivery?
A: We accept EXW,FOB,CIF,etc. You can choose the one which is the most convenient or cost effective for you.
Q:How long will it take if asking for the samples?
A: General speaking, 3-5 working days if asking for our regular items.
Q:What is your lead time for the mass products such as 500 units per item?
A: General speaking, about 15 working days after getting down payment and confirmation about the samples.
Q:What is your payment terms?
A: T/T, paypal, western union, or L/C.
Q: What are your market reach throughout the region?
A:Our markets around the world in every corner, we have 14 years of experience in foreign trade.
Q:What is your main product line is made?
A:We mainly produce led application classes and industrial lighting fixtures. Including daily life indoor lighting.
(led track light, led panel light, led strip, led linear light, led high bay, led floodlight, led stadium light, led street light solar street lights etc)
Q:Your factory or trading company?
A:We are a factory, we provide OEM services.
